VHA Shifts Priorities to 206 Main Rotor Blade Development

Van Horn Aviation recently shifted its development priorities to focus on the 206 main rotor blade program after the MD500 main rotor blade flight test program was cut short by unexpected unavailability of the test aircraft.

From August through early December 2013, the VHA flight test team achieved successful track and balancing of newly redesigned MD530F main rotor blades, high-g maneuvers, and forward flights to 130 kts during flight testing on an MD530F at MD Helicopters’ Mesa, Ariz., facility. However, MD Helicopters determined they had other priorities for the aircraft and terminated the program before all flight testing required for FAA certification could be completed.

The knowledge and experience gained from the MD530F flight test program will be carried over to the 206 main rotor blade program. VHA intends to resume certification testing of the MD500 series main and tail rotor blades after purchasing its own test helicopter in fourth quarter 2014.

< Older Post

Newer Post >

SHARE THIS POST:

AD Compliance Reminder for Certain 206L MRB Operators

By Kim VHA • April 25, 2025

For 206L LongRanger operators flying P/N 20633000-101 serial numbers A007-A009 or A012-A104, we would like to remind you that these blades are subject to AD 2022-22-08, which requires recurring tap inspections every 400 flight hours or 2,400 engine starts, whichever comes first. You can learn more about the tap test requirements and procedure in our video . These blades are likely to develop a delamination in the area of the weight pocket on the lower surface of the blade. The AD further requires removing the blades from service if the delamination reaches 6 inches in length. However, extensive company testing indicates that all blades will likely achieve their full retirement life before that occurs. So long as the delamination is monitored and does not exceed the permitted length, the blades are entirely safe to fly with no adverse effects on aircraft behavior or performance. Operators are required to report their findings at every inspection interval to VHA for tracking using the form on the last page of Service Bulletin 33000-4 . Completed forms should be emailed to info@vanhornaviation.com . Providing this data helps to ensure all operators of these blades remain safe. All of the identified blades are likely to have delaminations, so if none are detected please contact us for assistance. In addition, this AD is considered an interim action and once sufficient data is gathered it may be updated to reduce the required frequency of inspection. Refer to AD 2022-22-08 and SB 33000-4 for further information.
